Description
Product Description
Quincy 4152002717 QGS 5-HP 60-Gallon Rotary Screw Air Compressor w/ Dryer (208-230/460V 3-Phase)
Superior Compressed Air Turn-Key Performance
Oil injected twin screw pump provides reliable, quiet power
Integrated Refrigerated Air Dryer
Condenses the air to remove airborne moisture, dirt, and oil
Continuous 100% Duty Cycle
Runs your application efficiently 24/7
Standard Quiet Enclosure
Runs without the vibration & noise of piston compressors
Ideal for most applications; 15.6 CFM at 150 PSI
62 dBA for reduced sound fatigue in work area installations
Premium Synthetic Lubrication
Rated for 8,000 hours; low oil carryover protects tools
Start/Stop Operation
UL and cUL control panel compliant; 36°F minimum temperature
Long Life V-Belt Drive
Less maintenance, reliable operation
TEFC Electric Motor
3-phase unit runs on 200,208/230 or 460V power (IP 55 wash down); must be wired on-site by a licensed electrician
Extended 3 Year Factory Warranty Available
Must register with Quincy & use Quincy Maintenance Kits
True Blue 5-Year Warranty with Quincy Authorized Start Up
Covers airend, motor, separator reservoir, cooler/heat exchanger
Product Features
- Superior Compressed Air Turn-Key Performance
- ntegrated Refrigerated Air Dryer
- Continuous 100% Duty Cycle
- Standard Quiet Enclosure
- Premium Synthetic Lubrication
- Start/Stop Operation
- Long Life V-Belt Drive
- TEFC Electric Motor
- Extended 3 Year Factory Warranty Available
- True Blue 5-Year Warranty with Quincy Authorized Start Up
Product Specifications
General Information
| Product Category | Air Compressor – Stationary |
Motor
| Voltage | 208-230/460 Volt AC |
| Phase | Three Phase |
| dBA | 62 |
| Amp Draw | 28 |
| Recommended Breaker | 60 Amp Breaker |
Engine
| HP | 5 |
| Engine Low Oil Shut-off | Yes |
Pump
| CFM | 15.6 |
| CFM Rated @ | 150 PSI |
| Max PSI | 150 PSI |
| Oil Sight Glass | Yes |
| Pump Type | Rotary |
| After Cooler | No |
| Pump Drive | Belt Drive |
| Oil Type | Oil Lubricated |
| Pump Low Oil Shut-off | Yes |
| Duty Cycle | 100% |
Tank
| Tank Size | 60 Gallons |
| Tank Included | Yes |
| Tank Outlet | 1/2 Inch |
| Electronic Drain Valve | No |
| Tank Orientation | Horizontal |
Accessories
| Air Dryer | Yes |
| Air Filter | Yes |
Overview
| Weight | 543 Pounds |
| Certification | ASME |
| Consumer Warranty | 1 Year |
| Commercial Warranty | 1 Year |
| Product Length | 56 Inches |
| Product Width | 23 Inches |
| Product Height | 51 Inches |
| Power Type | Electric |
Downloads
Brochure
Manual
Warranty
�
